Reliable PTO-04 284Nm Power Take Off Solution

ベンダー:BXHS

製品タイプ:パワーテイクオフ

製品シリーズ:PTOシリーズ パワーテイクオフ

梱包サイズ:22*18*18

総重量:7.80 kg

在庫状況: 在庫あり

168 この製品を探している人もいます

Reliable PTO-04 284Nm Power Take Off Solution

Reliable PTO-04 284Nm Power Take Off Solution

Reliable PTO-04 284Nm Power Take Off Solution drawing image

Engineered by a Professional Manufacturer with 25+ years of expertise, this PTO-04 delivers 284Nm rated output torque and a 1:19 speed ratio via pneumatic control. Designed for wheel loaders, backhoes, and agricultural machinery, it ensures reliable power transmission. Backed by IATF 16949 certification and 100% testing, it offers Factory Direct Sales quality for global OEMs.

PTOシリーズ パワーテイクオフ パラメーター
制御空気圧 8-12 bar
潤滑オプション 圧力潤滑
取り付けオプション 標準取り付け
操作形式 空圧(単動シリンダー)スプリングリセット
出力方向 エンジン操舵方向と逆
定格出力トルク 350 Nm, 284 Nm
速度比 1.14, 1:1.2
制御方式 空圧制御
取付方式 8ボルト, 4ボルト

**1. High-Torque Power Take Off for Heavy Duty Use**
- Delivers a rated output torque of 284Nm with a precise 1:19 speed ratio, ensuring efficient power transfer for demanding applications.
- Features pneumatic control for smooth, responsive engagement, ideal for material handling and construction equipment requiring consistent performance.

**2. Versatile PTO for Wheel Loader & Agricultural Machinery**
- Specifically engineered to fit wheel loaders, backhoe loaders, skid steers, telehandlers, and harvesters with a standard 6-bolt mounting type.
- Compatible with major international brands, offering a cost-effective replacement solution without compromising on fit or function for industrial vehicles.

**3. Reliable Pneumatic PTO with 100% Quality Assurance**
- Manufactured in our 68,000㎡ facility equipped with 260+ vertical machining centers, ensuring strict dimensional accuracy and durability.
- Every unit undergoes 100% bench testing for pressure, flow, and sealing integrity, backed by CE compliance and SGS professional detection reports.

**4. Customizable Hydraulic Power Take Off Solutions**
- Supported by 35+ senior engineers, we offer full OEM/ODM services including custom casting, appearance design, and laser logo marking.
- As a China Wholesale factory, we provide flexible private label options to help distributors build their brand identity with minimal MOQ constraints.

**5. Factory Direct Sales with Global Export Capability**
- Benefit from Factory Direct Sales pricing with an annual capacity of 1,500,000 units, ensuring stable supply for large-scale wholesale orders.
- Products are secured with rust-proof treatment and heavy-duty wooden crate packaging, guaranteeing safe delivery for Exported Worldwide shipments.
