Premium Hydraulic Components: P40-AQF-G38-G12 from Top Manufacturers

制御方法:手動

スプール:2スプール

定格流量:毎分40リットル (10.5 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:G1/2

吐出口:G1/2

ポートサイズ:G3/8

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P40シリーズ モノブロック方向制御弁

梱包サイズ:23*18*13

総重量:5.50 kg

在庫状況: 在庫あり

1036 この製品を探している人もいます

Premium Hydraulic Components: P40-AQF-G38-G12 from Top Manufacturers

Premium Hydraulic Components: P40-AQF-G38-G12 from Top Manufacturers

Premium Hydraulic Components: P40-AQF-G38-G12 from Top Manufacturers drawing image

The P40-AQF-G38-G12 is a premium integral hydraulic valve designed for demanding applications in material handling, construction, earthmoving, agriculture, and industrial vehicles. This monoblock valve features manual control, a 2-section design, and a rated flow of 40 L/min, making it ideal for use in telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and backhoe loaders.

P40シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, ソレノイド・ジョイスティック, 手動・ジョイスティック, ソレノイドおよびケーブル式
スプール 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
構造タイプ モノブロック弁
セクション 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)
定格流量 毎分40リットル (10.5 US gpm)
最大圧力 250 bar (3600 psi)
吸入口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
吐出口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
ポートサイズ G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-AQF-G38-G12 is a high-performance integral hydraulic valve designed for demanding applications in various industries. It features a robust monoblock valve design with manual control for precise operation. With a 2-section configuration and a rated flow of 40 L/min (10.5 US gpm), this valve can handle high flow rates and pressures. The P40-AQF-G38-G12 is capable of operating at pressures up to 250 bar (3600 psi) and can handle a wide viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). This valve is designed for reliable performance even in extreme environments, with an operating temperature range of -40°C to +80°C (-40°F to +176°F). It is specifically suited for use in various heavy-duty applications including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and backhoe loaders. The P40-AQF-G38-G12 combines premium quality, high performance, and versatility, making it an ideal choice for demanding hydraulic applications.
