P80-AQF Directional Valve: Factory Direct Supply & Distribution

制御方法:手動

スプール:2スプール

定格流量:毎分80リットル (21.2 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:G1/2

吐出口:G3/4

ポートサイズ:G1/2

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P80シリーズ モノブロック方向制御弁

梱包サイズ:26*18*11

総重量:8.20 kg

在庫状況: 在庫あり

1044 この製品を探している人もいます

P80-AQF Directional Valve: Factory Direct Supply & Distribution

P80-AQF Directional Valve: Factory Direct Supply & Distribution

P80-AQF Directional Valve: Factory Direct Supply & Distribution drawing image

The P80-AQF Directional Valve is a high-performance, 4-way manual control hydraulic valve designed for various applications in material handling, construction, agriculture, and industrial vehicles. It offers a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi).

P80シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, 手動・ジョイスティック
スプール 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
構造タイプ モノブロック弁
セクション 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)
定格流量 毎分80リットル (21.2 US gpm)
最大圧力 315 bar (4600 psi)
吸入口 G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
吐出口 G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
ポートサイズ G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-AQF Directional Valve is a reliable and efficient solution for controlling hydraulic circuits in a wide range of machinery. This 4-way, 2-section monoblock valve features manual control and is designed for high-performance applications. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve is suitable for demanding environments. Its robust construction and wide operating temperature range (-40°C to +80°C) ensure durability and reliability. The P80-AQF Directional Valve is commonly used in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini excavators, skid steer loaders, compact wheel loaders, tractors, front-end loaders, harvesters, bale wrappers, backhoes, seeding machines, sprayers, and balers. Its versatility and robust design make it an ideal choice for various hydraulic systems in demanding applications.
