P40-XNHJ Hydraulic Valve: Distributors & Wholesalers Wanted Globally

制御方法:手動

スプール:2スプール

定格流量:毎分40リットル (10.5 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:G1/2

吐出口:G1/2

ポートサイズ:G3/8

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P40-XNHJ シリーズ モノブロック方向制御弁

梱包サイズ:23*18*11

総重量:5.00 kg

在庫状況: 在庫あり

513 この製品を探している人もいます

P40-XNHJ Hydraulic Valve: Distributors & Wholesalers Wanted Globally

P40-XNHJ Hydraulic Valve: Distributors & Wholesalers Wanted Globally

P40-XNHJ Hydraulic Valve: Distributors & Wholesalers Wanted Globally drawing image

The P40-XNHJ series hydraulic valve is a robust, high-performance 2-section monoblock valve rated at 40 L/min and 250 bar, ideal for various applications in material handling, construction, and agriculture. We are a manufacturer seeking global distributors, wholesalers, and trading partners.

P40-XNHJ シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, 手動・ジョイスティック
スプール 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール
定格流量 毎分40リットル (10.5 US gpm)
最大圧力 250 bar (3600 psi)
吸入口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
吐出口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
ポートサイズ G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
セクション 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション
構造タイプ モノブロック弁
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)

We are a global manufacturer of high-quality hydraulic valves, specializing in the P40-XNHJ series. This manual, 2-section monoblock valve boasts a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). It operates within a viscosity range of 15-75 mm²/s (15-75 cSt) and an ambient temperature range of -40°C to +80°C (-40°F to +176°F). The valve features a 2-spool design and is perfect for a wide range of applications including material handling, construction, and agriculture equipment such as forklifts, telehandlers, skid steer loaders, tractors, mini-excavators, backhoes, balers, harvesters, and sprayers.

We offer a full range of services including manufacturing, OEM, private labeling, customization, and wholesale distribution. We are actively seeking reliable distributors, wholesalers, and trading partners worldwide to expand our market reach. As a factory direct supplier, we offer competitive pricing and high-quality products. Partner with us to provide your customers with superior hydraulic valve solutions. Contact us today to discuss collaboration opportunities and explore the potential of a mutually beneficial partnership. Benefit from our factory direct wholesale pricing and exceptional product quality. We are committed to providing excellent service and support to all of our partners.
