生産と納品
15~30日の生産リードタイム



This P40 Series hydraulic solenoid valve is a high-performance directional control valve designed for demanding applications in construction, material handling, agriculture, and industrial vehicles. It features a 220 Volt operation, high pressure rating, long service life, and a compact monoblock structure.
| P40シリーズ モノブロック方向制御弁 パラメーター | |
|---|---|
| 制御方法 | 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, ソレノイド・ジョイスティック, 手動・ジョイスティック, ソレノイドおよびケーブル式 |
| スプール | 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール |
| 周囲温度範囲 | -40°C to +80°C (-40°F to +176°F) |
| 構造タイプ | モノブロック弁 |
| セクション | 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション |
| 作動粘度範囲 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 定格流量 | 毎分40リットル (10.5 US gpm) |
| 最大圧力 | 250 bar (3600 psi) |
| 吸入口 | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| 吐出口 | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| ポートサイズ | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
The P40-U34 directional valve is a robust and reliable hydraulic solenoid valve built for heavy-duty applications. This 220 Volt valve provides precise control of hydraulic fluid flow with a maximum pressure rating of 250 bar (3600 psi). The valve boasts a long service life, thanks to its durable construction and high-quality materials. Designed as a monoblock valve, the P40-U34 offers a compact and efficient solution for a wide range of applications. It is perfect for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. The valve's operating viscosity range of 15-75 mm²/s (15 cSt to 75 cSt) and ambient temperature range of -40°C to +80°C (-40°F to +176°F) ensure reliable operation in a variety of harsh environments.
