P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label

制御方法:手動

スプール:2スプール

定格流量:毎分40リットル (10.5 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:SAE 8

吐出口:SAE 8

ポートサイズ:SAE 8

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P40シリーズ モノブロック方向制御弁

梱包サイズ:23*18*13

総重量:4.80 kg

在庫状況: 在庫あり

1020 この製品を探している人もいます

P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label

P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label

P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label drawing image

This P40 Series Directional Control Valve is a manually operated, monoblock valve designed for heavy-duty applications in construction, material handling, agriculture, and industrial vehicles. It features a 2-section design, a rated flow of 40 L/min, and a maximum pressure of 250 bar. The valve is customizable and available with private label options.

P40シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, ソレノイド・ジョイスティック, 手動・ジョイスティック, ソレノイドおよびケーブル式
スプール 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
構造タイプ モノブロック弁
セクション 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)
定格流量 毎分40リットル (10.5 US gpm)
最大圧力 250 bar (3600 psi)
吸入口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
吐出口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
ポートサイズ G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

This high-performance P40 Series Directional Control Valve is a reliable solution for various applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. Its manual operation provides precise control over hydraulic circuits. The valve is engineered with a robust monoblock structure for superior durability and long service life. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve delivers efficient performance in demanding environments. It operates within a wide viscosity range of 15-75 mm²/s (15 cSt to 75 cSt) and withstands ambient temperatures from -40°C to +80°C (-40°F to +176°F). We offer customization options to meet your specific requirements. This valve is also available for private label branding, allowing you to create a unique identity for your products.
