P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

制御方法:手動

スプール:3スプール

定格流量:120 L/分 (31.7 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:G1

吐出口:G1

ポートサイズ:G1

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P120シリーズ モノブロック方向制御弁

梱包サイズ:37*37*18

総重量:24.10 kg

在庫状況: 在庫あり

1333 この製品を探している人もいます

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support drawing image

The P120-G1-OT Hydraulic Forward And Reverse Valve is a high-performance, manual control monoblock valve designed for a variety of construction, material handling, and industrial applications. It features a 3-section design, 120 L/min rated flow, and a maximum pressure of 250 bar.

P120シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, ケーブル, ジョイスティック, 手動・ジョイスティック
スプール 1スプール, 2スプール, 3スプール, 4スプール
定格流量 120 L/分 (31.7 US gpm)
最大圧力 250 bar (3600 psi)
吸入口 G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
吐出口 G1, SAE 16, 1 NPT, M36×2
ポートサイズ G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
セクション 1セクション, 2セクション, 3セクション, 4セクション
構造タイプ モノブロック弁
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)

This P120 Series hydraulic valve is a 3-section, manual control monoblock valve with a rated flow of 120 L/min and a maximum pressure of 250 bar. It is ideal for use in a wide range of applications, including construction equipment (telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders), material handling equipment (telehandlers, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers), and agricultural machinery. The valve operates with an operating viscosity range of 15 - 75 mm²/s and is suitable for ambient temperatures ranging from -40°C to +80°C. The P120-G1-OT valve offers reliable performance and durability, making it an excellent choice for demanding applications.
