Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM

制御方法:手動

スプール:1スプール

定格流量:毎分40リットル (10.5 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:G3/8

吐出口:G3/8

ポートサイズ:G3/8

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P40シリーズ モノブロック方向制御弁

梱包サイズ:23*16*11

総重量:3.00 kg

在庫状況: 在庫あり

1004 この製品を探している人もいます

Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM

Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM

Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM drawing image

The P40-G38-OT Series Manual Monoblock Directional Valve is a high-performance hydraulic valve designed for various applications including wood splitting, material handling, construction, and agriculture. It features a compact monoblock construction, manual control, and a rated flow of 40 L/min, making it ideal for a wide range of hydraulic systems.

P40シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, ソレノイド・ジョイスティック, 手動・ジョイスティック, ソレノイドおよびケーブル式
スプール 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
構造タイプ モノブロック弁
セクション 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)
定格流量 毎分40リットル (10.5 US gpm)
最大圧力 250 bar (3600 psi)
吸入口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
吐出口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
ポートサイズ G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G38-OT Series Manual Monoblock Directional Valve is a robust and reliable hydraulic component designed for demanding applications. This 1-section valve features a compact monoblock construction, ensuring durability and ease of installation. The manual control method allows for precise and convenient operation. With a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve is suitable for a wide range of hydraulic systems. Its operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and ambient temperature range of -40°C to +80°C (-40°F to +176°F) ensure optimal performance in various environmental conditions. The P40-G38-OT Series valve is specifically designed for applications such as material handling, construction, and agriculture, making it suitable for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and backhoe loaders.
