Hydraulic Directional Valve - P120-G1-OT Series | Wholesale & OEM

制御方法:手動

スプール:3スプール

定格流量:120 L/分 (31.7 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:G1

吐出口:G1

ポートサイズ:G1

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P120シリーズ モノブロック方向制御弁

梱包サイズ:37*37*18

総重量:24.10 kg

在庫状況: 在庫あり

1004 この製品を探している人もいます

Hydraulic Directional Valve - P120-G1-OT Series | Wholesale & OEM

Hydraulic Directional Valve - P120-G1-OT Series | Wholesale & OEM

Hydraulic Directional Valve - P120-G1-OT Series | Wholesale & OEM drawing image

The P120-G1-OT series manual hydraulic directional valve is a 3-section, monoblock valve designed for use in a variety of construction and industrial applications. This valve features a rated flow of 120 L/min and a maximum pressure of 250 bar. It is available for wholesale and OEM orders.

P120シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, ケーブル, ジョイスティック, 手動・ジョイスティック
スプール 1スプール, 2スプール, 3スプール, 4スプール
定格流量 120 L/分 (31.7 US gpm)
最大圧力 250 bar (3600 psi)
吸入口 G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
吐出口 G1, SAE 16, 1 NPT, M36×2
ポートサイズ G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
セクション 1セクション, 2セクション, 3セクション, 4セクション
構造タイプ モノブロック弁
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)

The P120-G1-OT series manual hydraulic directional valve is a high-performance, reliable valve designed for use in demanding applications. It features a 3-section, monoblock design for durability and ease of maintenance. The valve is rated for a flow rate of 120 L/min and a maximum pressure of 250 bar, making it suitable for a wide range of construction, material handling, and industrial equipment. It is available for wholesale and OEM orders, allowing you to customize the valve to meet your specific needs. The valve is also compatible with a variety of applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini excavators, midi excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, and dumpers.
