High-Performance P81 Valve for Demanding Hydraulic Applications

制御方法:手動

スプール:1スプール

定格流量:毎分80リットル (21.2 US gpm)

最大圧力:19 MPa (2735 psi)

吸入口:G1/2

吐出口:G3/4

ポートサイズ:G3/4

ベンダー:BXHS

製品タイプ:薪割り機用コントロールバルブ

製品シリーズ:P81シリーズ 薪割り機用コントロールバルブ

梱包サイズ:27*16*12

総重量:4.80 kg

在庫状況: 在庫あり

1686 この製品を探している人もいます

High-Performance P81 Valve for Demanding Hydraulic Applications

High-Performance P81 Valve for Demanding Hydraulic Applications

High-Performance P81 Valve for Demanding Hydraulic Applications drawing image

The P81 Series Multiway Directional Valve is a high-performance hydraulic valve designed for demanding applications in industrial vehicles, particularly wood splitters. This manual control valve features a monoblock structure and delivers a rated flow of 80 L/min (21.2 US gpm) at a maximum pressure of 250 bar (3600 psi).

P81シリーズ 薪割り機用コントロールバルブ パラメーター
制御方法 手動
スプール 1スプール
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
構造タイプ モノブロック弁
セクション 1セクション
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)
定格流量 毎分80リットル (21.2 US gpm), 毎分95リットル (25.1 US gpm)
最大圧力 19 MPa (2735 psi)
吸入口 G1/2
吐出口 G1/2
ポートサイズ G3/4

The P81 Series Multiway Directional Valve is a robust and reliable solution for controlling hydraulic systems in demanding industrial applications. This high-performance valve is specifically designed for wood splitters, offering superior control and efficiency. Its monoblock construction provides durability and strength, ensuring long-lasting performance. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 250 bar (3600 psi), the P81 valve is capable of handling high-pressure hydraulic systems. The valve operates within a wide viscosity range (15 - 75 mm²/s) and can withstand temperatures from -40°C to +80°C. Its kick-out setting pressure is adjustable between 70~140bar (1015-2030psi), providing precise control and safety. The P81 Series Multiway Directional Valve is an ideal choice for manufacturers and users of industrial vehicles and equipment requiring a high-performance, reliable, and durable hydraulic valve solution.
