Heavy Duty P51A646TEYR25-25 Hydraulic External Gear Pump

変位:104.5 cc/rev

定格圧力:16 MPa (2320 psi)

最大圧力:17 MPa (2465 psi)

最大回転速度:2400 r/min

回転方向:双方向

ベンダー:BXHS

製品タイプ:油圧ギア・ポンプ

製品シリーズ:P51シリーズ 油圧ギア・ポンプ

梱包サイズ:34*17*17

総重量:24.00 kg

在庫状況: 在庫あり

145 この製品を探している人もいます

Heavy Duty P51A646TEYR25-25 Hydraulic External Gear Pump

Heavy Duty P51A646TEYR25-25 Hydraulic External Gear Pump

Heavy Duty P51A646TEYR25-25 Hydraulic External Gear Pump drawing image

As a leading manufacturer of large-scale hydraulic solutions, we offer the high-performance P51A646TEYR25-25 Hydraulic External Gear Pump. This heavy-duty series features a 104.5 cc/rev displacement and bidirectional rotation, designed for stable power transmission in demanding industrial and mobile applications.

P51シリーズ 油圧ギア・ポンプ パラメーター
変位 104.5 cc/rev, 21 cc/rev, 41.8 cc/rev, 52.3 cc/rev, 62.7 cc/rev, 64.6 cc/rev
定格圧力 16 MPa (2320 psi)
最大圧力 17 MPa (2465 psi)
定格回転速度 2200 r/min
最大回転速度 2400 r/min
回転方向 双方向
材質 鋳鉄
構造 外部齒輪泵
フランジモデル A-橢圓形凸緣, ISO-4 安裝孔, SAEフランジ
軸タイプ X:漸開線花鍵

Our factory specializes in the mass production of the P51A646TEYR25-25 Heavy Duty Hydraulic External Gear Pump, delivering 104.5 cc/rev displacement with a rated pressure of 16 MPa (2320 psi). Engineered for versatility, this bidirectional model supports speeds ranging from 600 to 2400 r/min, making it suitable for a wide variety of construction, agricultural, and industrial machinery. As a global manufacturing partner, we provide comprehensive services including OEM, private labeling, and custom engineering to meet specific technical requirements. We are currently expanding our international network and actively seeking long-term cooperation with distributors, wholesalers, agents, and professional traders. By sourcing directly from our facility, partners benefit from reliable factory supply, competitive wholesale pricing, and rigorous quality control. Whether you need bulk orders for retail or specialized units for large-scale equipment, our manufacturing expertise ensures performance and durability in every pump.
