DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type

制御方法:電気油圧

スプール:1スプール

定格流量:毎分60リットル (15.8 US gpm)

最大圧力:315 bar (4600 psi)

吸入口:G1/2

吐出口:G1/2

ポートサイズ:G1/2

ベンダー:BXHS

製品タイプ:セクショナル方向弁

製品シリーズ:DCV60シリーズ セクショナル方向弁

Packagingsize:39*23*21

Grossweight:11.60 kg

在庫状況: 在庫あり

91 この製品を探している人もいます

DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type

DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type

DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type drawing image

The DCV60 Series is a high-performance, single-spool electro-hydraulic directional control valve engineered for heavy-duty mobile applications. Featuring a 60 L/min flow rate and 350 bar pressure capacity, it offers precise control for construction, agricultural, and material handling equipment.

DCV60シリーズ セクショナル方向弁 パラメーター
制御方法 手動, 空圧, 電空, 電気油圧, 油圧, 油圧および手動, ケーブル, ジョイスティック, ソレノイドおよび手動, ソレノイド・ジョイスティック, 手動・ジョイスティック, 電動モーター
スプール 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール, 8スプール, 9スプール, 10スプール, 11スプール, 12スプール
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
構造タイプ ブロック弁
セクション 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション, 8セクション, 9セクション, 10セクション, 11セクション, 12セクション
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)
定格流量 毎分60リットル (15.8 US gpm)
最大圧力 315 bar (4600 psi), 350 bar (5100 psi)
吸入口 G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
吐出口 G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
ポートサイズ G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT

As a leading manufacturer of hydraulic components, we specialize in high-precision directional control valves designed for demanding operational environments. Our DCV60 Series provides reliable performance for various machinery, including tractors, mini-excavators, and material handling vehicles. We are committed to supporting global partners through flexible cooperation models, including OEM, ODM, private labeling, and custom engineering services. Our factory-direct supply chain ensures consistent quality and competitive wholesale pricing for global distributors, wholesalers, and international traders. Whether you require standard inventory or specialized, application-specific configurations, our production team is equipped to meet your technical specifications with efficiency and professional support. We are actively seeking long-term partnerships with distributors, wholesalers, and trade companies worldwide to expand our market reach and deliver high-value hydraulic solutions to the construction and agricultural sectors.
