Buy P40-S 4-Spool Monoblock Directional Valves - Factory Supply

制御方法:ソレノイド

スプール:4スプール

定格流量:毎分40リットル (10.5 US gpm)

最大圧力:250 bar (3600 psi)

吸入口:G1/2

吐出口:G1/2

ポートサイズ:G3/8

ベンダー:BXHS

製品タイプ:モノブロック方向制御弁

製品シリーズ:P40シリーズ モノブロック方向制御弁

梱包サイズ:35*23*15

総重量:12.70 kg

在庫状況: 在庫あり

580 この製品を探している人もいます

Buy P40-S 4-Spool Monoblock Directional Valves - Factory Supply

Buy P40-S 4-Spool Monoblock Directional Valves - Factory Supply

Buy P40-S 4-Spool Monoblock Directional Valves - Factory Supply drawing image

High-quality P40 series 4-spool monoblock directional hydraulic valves, rated at 40 L/min and 250 bar, ideal for various applications including material handling, construction, and agriculture. Factory direct supply, offering OEM, private label, and custom solutions. Wholesale pricing available.

P40シリーズ モノブロック方向制御弁 パラメーター
制御方法 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, ソレノイド・ジョイスティック, 手動・ジョイスティック, ソレノイドおよびケーブル式
スプール 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール
周囲温度範囲 -40°C to +80°C (-40°F to +176°F)
構造タイプ モノブロック弁
セクション 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション
作動粘度範囲 15 - 75 mm²/s (15 cSt to 75 cSt)
定格流量 毎分40リットル (10.5 US gpm)
最大圧力 250 bar (3600 psi)
吸入口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
吐出口 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
ポートサイズ G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Buy high-performance P40-S 4-Spool Monoblock Directional Valves – direct from the factory! We are a leading manufacturer of hydraulic products supplying globally. Our P40 series offers superior performance and reliability. This robust 4-section monoblock valve boasts a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). Its solenoid control system and wide operating temperature range (-40°C to +80°C) ensure dependable operation in demanding environments.

**Key Features:**
* **Control Method:** Solenoid
* **Sections:** 4 Section
* **Structure Type:** Monoblock valve
* **Rated Flow:** 40 L/min (10.5 US gpm)
* **Max Pressure:** 250 bar (3600 psi)
* **Operating Viscosity:** 15 - 75 mm²/s (15 cSt to 75 cSt)
* **Temperature Range:** -40°C to +80°C (-40°F to +176°F)
* **Application:** MATERIAL HANDLING, CONSTRUCTION & EARTH MOVING, AGRICULTURE, INDUSTRIAL VEHICLES (Forklifts, Telehandlers, Skid Steer Loaders, Compact Wheel Loaders, Mini-Excavators, Tractors, Harvesters, Balers, Sprayers)

**We offer comprehensive solutions, including:**
* **Manufacturing:** High-quality production of hydraulic valves.
* **OEM (Original Equipment Manufacturing):** Customize valves to your specific requirements.
* **Private Labeling:** Brand your own hydraulic valves with your logo and branding.
* **Custom Design:** Tailor-made solutions for unique applications.
* **Wholesale Pricing:** Competitive pricing for large orders.

**We are actively seeking:**
* Distributors
* Wholesalers
* Agents
* Trading Companies

Partner with a reliable hydraulic valve manufacturer offering factory-direct pricing and exceptional service. Contact us today to discuss your needs and explore mutually beneficial collaboration opportunities. Factory direct wholesale pricing available! Contact us for a quote.
