生産と納品
15～30日の生産リードタイム
イノベーションが開発を推進し、テクノロジーが未来を築きます
1054 この製品を探している人もいます
Our Bespoke Hydraulic Solutions: Customizable P80-U78-4OT Directional Control Valves are designed to meet the specific requirements of various applications. These valves offer manual control, a 4-section monoblock structure, and a rated flow of 80 L/min at a maximum pressure of 250 bar. With 4 spools and a wide operating viscosity range, these valves are suitable for a variety of applications in material handling, construction, agriculture, and industrial vehicles.
| P80シリーズ モノブロック方向制御弁 パラメーター | |
|---|---|
| 制御方法 | 手動, 空圧, 電空, 電気油圧, ソレノイド, 油圧, 油圧および手動, ケーブル, ジョイスティック, 手動・ジョイスティック |
| スプール | 1スプール, 2スプール, 3スプール, 4スプール, 5スプール, 6スプール, 7スプール |
| 周囲温度範囲 | -40°C to +80°C (-40°F to +176°F) |
| 構造タイプ | モノブロック弁 |
| セクション | 1セクション, 2セクション, 3セクション, 4セクション, 5セクション, 6セクション, 7セクション |
| 作動粘度範囲 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 定格流量 | 毎分80リットル (21.2 US gpm) |
| 最大圧力 | 315 bar (4600 psi) |
| 吸入口 | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| 吐出口 | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| ポートサイズ | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
**Bespoke Hydraulic Solutions: Customizable P80-U78-4OT Directional Control Valves**
Our Bespoke Hydraulic Solutions provide customizable directional control valves tailored to your specific requirements. The P80-U78-4OT model is a 4-section, monoblock valve with manual control. It features a rated flow of 80 L/min and a maximum pressure of 250 bar. This valve has 4 spools and an operating viscosity range of 15 - 75 mm²/s. Its ambient temperature range is -40°C to +80°C.
**Key Features:**
* Customizable design to meet specific application requirements
* Manual control for precise operation
* 4-section monoblock structure for compact and efficient design
* High flow capacity of 80 L/min
* Robust construction for maximum durability
**Applications:**
Our P80-U78-4OT directional control valves are widely used in various applications, including:
* Material handling equipment
* Construction machinery
* Agricultural vehicles
* Industrial vehicles
**OEM, ODM, and Customization Services:**
We offer OEM, ODM, and customization services to meet the unique needs of our customers. Our team of experienced engineers can work with you to design and manufacture valves that perfectly match your specifications. Whether you need custom porting, spools, or other modifications, we have the expertise to deliver tailored solutions.
Contact us today to discuss your specific requirements and explore how our Bespoke Hydraulic Solutions can enhance your application.
